Name: Semi-Automatic Book Block Head Band Machine 1.5KW 220V 11pcs/minute for Medium and Small Book Binding
Brand: DONGGUAN MAUFUNG MACHINERY CO.,LTD
Price: 11.00 USD
Availability: InStock

홈 제품 소개 노트북 묶기 기계

Semi-Automatic Book Block Head Band Machine 1.5KW 220V 11pcs/minute for Medium and Small Book Binding

제품 상세 정보:

원래 장소:	광동, 중국
브랜드 이름:	MAUFUNG

결제 및 배송 조건:

최소 주문 수량:	1
가격:	$11,000-12,000

접촉

상세 제품 설명

자동등급:	반자동	힘:	1.5kw
전압:	220V	속도:	11개/분
종이 두께:	10-80mm	기계 치수:	W700L850H1550mm
최대 블록 크기:	350x420mm	최소 블록 크기:	100 Ｘ 100 밀리미터
무게:	2700kg	포장 크기:	L1000W820H1740MM
전원공급장치:	220V/1Ph/50Hz	메인프레임 전원:	1.5kw
책 두께:	10-80mm	모델 번호:	MF-HBM420
총 체중:	350kg
강조하다:	1.5KW Book Block Head Band Machine , 220V Notebook Binding Machine , 11pcs/minute Head Band Machine

Notebook Making Machine Book Edge Tail Band Machine Head Band Machine

Product Specifications

Model No	MF-HBM420
Power Supply	220V, 1Phase, 50HZ
Mainframe power	1.5kw
Work Speed	11PCS/minute
Book Block Thickness	10-80mm
Book Block Size (Max)	350x420mm
Book Block Size (Min)	100x100mm
Packing size (L×W×H)	L1000W820H1740MM
Machine Weight	2700KG(Net);350KG(Gross)

Product Overview

The Book Block Head Band Machine is a flexible and compact solution for applying head and tail bands to both round and square book blocks. Designed as the perfect solution for medium and small book binding companies, this machine joins the head band to the glue strip before application to the book spine. A significant advantage is that it requires no cleaning at the end of production.

Product Images

Certifications

Manufacturer Information

Dongguan Maufung Machinery Co., Ltd, located in Wanjiang district, Dongguan city, specializes in manufacturing case-maker hardcover, post-printing process, packaging, automatic gift box and pasting machines. Our product line includes Photo Book Lay Flat Machines, Book Block Head Band Machines, Semi Auto Case Makers, Hard Cover Book Case In Machines, and various other book binding and packaging equipment.

Our machines, sold under the MAUFUNG brand, are well-known in the Chinese domestic market and have been exported to over 100 countries including the United States, the Netherlands, Australia, and throughout Southeast Asia, Russia, the Middle East, and Africa.

We adhere to strict quality standards with our "People-oriented Principle, Quality for Survival Strategy, Credibility for Development Strategy" philosophy. Our comprehensive after-sales service includes installation, adjustment, and maintenance support. With first-class production equipment, technical expertise, product quality, and customer service, we have earned the trust of numerous companies worldwide.

Exhibition
